Ferrite Disc Magnets
Standard and custom ferrite disc magnets for motors, sensors, and magnetic assemblies with stable high-volume production.
Product Overview
Ferrite disc magnets are the most widely used permanent magnet format in industrial applications. Manufactured by wet or dry pressing of strontium/barium ferrite powder followed by high-temperature sintering at 1200–1250°C, they deliver consistent magnetic performance at a fraction of rare-earth cost. FerriteCustom produces ferrite discs from 3mm to 150mm diameter with thickness from 2mm to 30mm, supporting axial or diametric magnetization across Y30, Y30BH, Y35, and Y40 grades.
Technical Specifications
Available Grades
Y30, Y30BH, Y35, Y40
Size Range
Ø3–150 mm × 2–30 mm thick
Max Temp
250°C (300°C for Y30BH)
Process
Wet pressing / Dry pressing + Sintering
Surface Finish
As-sintered, Ground flat, Polished
Magnetization
Axial (through thickness), Diametric
Key Features
- Cost is 5–10× lower than NdFeB for equivalent flux density class applications
- Excellent corrosion resistance — no coating required in most environments
- Temperature stability superior to NdFeB above 150°C
- High-volume throughput: 100,000+ pcs/day production capacity per press line
- No supply chain risk from rare-earth market volatility
Customization
- Non-standard diameters and thicknesses to ±0.05 mm tolerance
- Custom magnetization direction (axial, diametric, or multi-pole)
- Surface grinding to Ra ≤ 1.6 μm for precision sensor applications
- Adhesive backing (3M-type) or epoxy coating for assembly integration
- Custom packaging per BOM and line-side delivery requirements
Typical Applications
